JSDB soule speed winch manufacturer from China Shandong China Coal Industry&Mining Supplies Group

Payment Terms:	T/T,L/C,WU,Paypal
Place of Origin:	Shandong, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Production Capacity: 1000sets/month

Delivery Date: 15 days

Packing: standard packaging

JSDBtwo-speed with fast and slow and two multi-purpose winch, mainly for underground coal mining face, mechanized mining equipment

chinacoal03

Double speed winch

JSDBtwo-speed with fast and slow and two multi-purpose winch, mainly for underground coal mining face, mechanized mining equipment and various types of mechanical and electrical equipment relocation and other auxiliary transport work, as well as underground mining face, shaft bottom, down the mountainmine surface, etc. the tramcar scheduling, material transport can also be used for the back of the stope pillar caving.

Feature:

1.top quality with competitive price.

2.widely used in the double beam bridge crane and gantry crane.

3.easy to install and high quality.

4.compact structure and reasonable design.

Model		JSDB-6			JSDB-16		JSDB-19		JSDB-30
		Fast	Slow		Fast	Slow	Fast	Slow	Fast	Slow
Static tension of wire rope	Outer max static tension (KN)	8	60		22	160	26	190	40	300
	Inner max static tension (KN)	16	100		38	280	50	320	82	470
	Average static tension (KN)	12	80		30	220	38	250	61	380
Rope speed	Max rope speed(outer layer)m/s	0.85	0.12		1.5	0.16	1.5	0.16	1.5	0.2
	Average rope speed m/s	0.6	0.085		1.16	0.12	1.1	0.12	1.1	0.15
Drum	Rope capacity (m)	100			300		400		700
Wire rope	Diameter (mm)	16			28		30		36
	Structure	Rope 6x19
	Nominal tensile strength MPa	1670
Motor	Model	YBK2-160M-6		YBK2-250M-6			YBK2-280S-6		YBK2-315S-6
	Power KW	7.5KW		37KW			45KW		75KW
Speed rpm		970		980			980		980
Dimension mm		2690850840		350512001250			350512001250		410015001300
Weight kg(including motor)		2000		4500			5500		10900
